TOPRT Wide is a premium wide-screen industrial HMI series for applications needing a larger operator workspace, a capacitive touch interface and a broad set of communication and peripheral options. The supplied 15.6 inch catalogue sheet describes a 16:9 wide display, a heavy-duty front aluminium frame and model-dependent options such as camera, Wi-Fi, Bluetooth and IrDA.
This series is intended for industrial automation environments where the HMI must be selected around the required interface layout, operator experience and installation method. Orbital Mekatronik can review the application inputs and help you request a suitable configuration or exact model.
| Parameter | Catalogue information |
|---|---|
| Catalogue family | TOPRT Wide Series |
| Referenced 15.6 inch model | TOPRT1550WD(-Ex) 00; confirm final code |
| Display | 15.6 inch TFT colour; 16M colours |
| Resolution | 1366 x 768; 16:9 wide format |
| Touch | Capacitive touch; IK07 tempered glass stated |
| CPU | Catalogue states twice the speed of TOPRT1210SD-Ex |
| Serial ports | COM1, COM2 and COM3; configuration varies by port |
| Ethernet | Two RJ-45 channels; 10 100 1000BASE-T stated |
| USB | Three USB host ports; rear USB 3.0 x 2 and front USB 2.0 x 1 stated |
| Wireless | Wi-Fi 2.4G 5G, Bluetooth 5.0 BLE and IrDA listed on applicable models |
| Other I O | Front camera, proximity sensor, audio, SD card and option-module capability listed |
| Power and protection | 24 VDC 20 to 28 VDC; IP66 stated; -10 to +50 C operation |
| Explosion-proof note | Catalogue says -Ex model is explosion-proof certified; exact certificate scope must be verified |
The wide 15.6 inch interface can suit screens with more process values, alarms, recipes and navigation.
The catalogue lists camera, proximity sensor, audio and optional modules; validate actual project needs and model support.
Serial, dual Ethernet and model-dependent wireless facilities provide a basis for integration planning.
Only evaluate an -Ex model after reviewing the exact certificate, markings, permitted installation and project compliance requirements.
For TOPRT Wide selection, share the screen layout requirement, viewing distance, PLC model and protocol, number of Ethernet and serial connections, required accessories, wireless policy, operating environment and whether any hazardous-area requirement applies. An -Ex label alone is not sufficient to establish suitability; the exact certification must match the installation requirement.
Confirm the exact model code, display size, ports, controller protocol, power requirement, mounting dimensions, environmental protection, optional hardware and certificate status before procurement. Do not assume a feature is included across every series variant.
Send the controller make and model, protocol, required screen size, panel or machine mounting details, power supply, quantity and site location. Orbital Mekatronik can help align the HMI selection with the integration requirement before you place the order.
